C2150FHF1MB01 21.5″ 1500:1 FHD Panel Embedded Automation

The TIANMA C2150FHF1MB01 is a solid 21.5-inch industrial FHD LCD module made for real-world factory and equipment environments where reliability matters more than flashy marketing. It runs at 1920×1080 (102 PPI) and uses a normally-black SFT structure with wide 89° viewing angles, so the picture stays consistent even when you’re not looking at it perfectly straight on.

For brightness and readability, it delivers 500 nits typical and a strong 1500:1 contrast ratio, which is great for industrial HMIs, kiosks, control panels, and machine displays. The anti-glare surface (Haze 25%) helps cut down reflections, making it easier to read under overhead lighting. Motion performance is also reasonable for UI use, with a typical 20 ms response time and 60 Hz refresh.

Integration is straightforward: the panel uses dual-channel 8-bit LVDS through a 30-pin connector and a 5.0V supply. The backlight is WLED (19S4P) rated for 50,000 hours, but it comes without a built-in backlight driver, which gives system designers flexibility to choose their own driver solution. With -20 to 70°C operating and -30 to 80°C storage ratings, it’s a dependable choice for long-running industrial deployments.
