49 Inch High Brightness LCD Panel Display UHD 3500 Nits for Digital Signage

Product Gallery
Key Specs

Model P/N

HS490ENT-N35

Size

49″

Resolution

3840×2160

Brightness

2500 (Typ.)(cd/m²)

Viewing Angle

89/89/89/89

Connector Type

V-by-One 8 Lane, 51 Pins

Operating Temp

-20 ~
70 °C

Overall(mm)

1078.4(W)×
608.6(H)×
15(D)
Upgrade Options (OEM/ODM)

huisoar

HS490ENT-N35

General Features

Brand

huisoar

Panel Size (inch)

49"

Model P/N

HS490ENT-N35

Resolution

3840×2160

Brightness (nits)

2500 cd/m² (Typ.)

Viewing Angle

89/89/89/89

Contrast Ratio

1100:1

Response Time

8 ms (G-to-G)

Overall (mm)

1078.4(W)×
608.6(H) ×
15(D) mm

Active Area (mm)

1073.8 × 604 mm

Refresh Rate

120Hz

Bezel Opening

1078.4×608.6 mm

Display Colors

1.07 Billion Colors, 68% NTSC

Panel Type

tft-lcd, lcm, ips-tft-lcd-panel

Connector Type

V-by-One 8 Lane, 51 Pins

Surface Treatment

Matte (Haze 28%), Hard Coating (2H)

Operating Temp

-20 ~
70 °C

Touchscreen Type

Optional

Storage Temp

-30 ~ 80 °C

Work Mode

IPS, Normally Black, Transmissive

Pixel Format

RGB Vertical Stripe

Input Voltage (V)

12.0V Typical

Weight (g)

11600 g(Typ./Max.)

Designed For

Window-Facing, Digital Signage, Outdoor

A 4K IPS commercial display panel engineered for smart city infrastructure, transportation systems, and high ambient light digital signage applications.

For window-facing commercial screens, ordinary indoor panels often lose impact once ambient light becomes too strong. This 49 Inch High Brightness LCD Panel is built for that challenge, combining a 49 inch format, 3840 × 2160 UHD resolution, 3500 nits typical brightness with glass, IPS wide viewing, and 24/7 operating capability. It is positioned for retail and hospitality environments that need strong screen visibility, stable long-hour use, and a display platform suitable for custom integration into professional signage systems.

Why a 49 Inch High Brightness LCD Panel Display Works for Retail

Optical Value of the 49 Inch High Brightness LCD Panel Display

The clearest advantage of this product is its balance between screen size, pixel density, and brightness. A 49 inch UHD panel provides four times the definition of Full HD, which helps stores and commercial venues present sharper text, cleaner product imagery, and more detailed promotional layouts. On top of that, the detailed specification lists 3500 nits typical brightness with glass, which is far above standard indoor display levels and is intended to keep content more visible in direct or near-direct sunlight. For window-facing signage, that combination supports stronger message delivery without relying only on oversized screen formats.

Wide Viewing Performance for Public-Facing Content

In commercial environments, viewers rarely stand in a single centered position. The panel uses IPS technology, a normally black transmissive mode, and a 178° × 178° viewing structure, helping the screen maintain more stable image presentation from different angles. The page also lists 1.07 billion colors, 63% NTSC color coverage, and an antiglare surface with 1% haze, which together support clearer image perception under bright viewing conditions. For retail display planning, these characteristics are useful because they improve the chance that promotional visuals remain readable and visually consistent across a wider customer path.

Selection Advantages for Commercial Display Projects

4K Clarity, 24/7 Use, and Long Backlight Life

From a procurement perspective, a 49 Inch High Brightness LCD Panel becomes more valuable when optical performance is supported by long-hour operation. This model is described as suitable for 24/7 use and lists a 50,000-hour backlight life, which is important for projects that need day-long advertising playback or fixed information display in storefronts and public spaces. The 1100:1 contrast ratio and 6 ms typical response time also help support cleaner motion handling and stable image presentation for video loops, price promotions, brand campaigns, and hospitality messaging. These factors make the panel more relevant for B2B commercial deployment than a standard consumer television panel.

Practical Fit for Window-Facing Integration

The source page identifies the product as a window-facing display and lists applications such as supermarkets, shopping centers, car dealerships, wedding shops, hotels, tourism, and the wider retail and hospitality industry. That application direction matters because it shows the panel is being positioned for outward-facing use rather than ordinary indoor menu boards. The active area of 1073.78 × 604 mm and support for both portrait and landscape installation give system designers flexibility when planning custom housings, storefront media frames, or integrated commercial display equipment. This makes the panel suitable for projects that require strong visibility along with format flexibility in real store environments.

Application Direction for Retail and Hospitality Signage

Where This 49 Inch High Brightness LCD Panel Display Creates Value

In practical use, this 49 Inch High Brightness LCD Panel fits storefront promotions, restaurant windows, shopping mall advertising, hotel information screens, and vehicle showroom messaging where strong daylight exposure can wash out conventional panels. The 49 inch size is large enough for impactful visual communication while remaining easier to integrate than much larger signage formats. Because the product is presented as a commercial sunlight-readable panel rather than a finished consumer monitor, it also gives OEM and system-integration buyers more room to build project-specific housings, cooling structures, and control solutions around the screen.

Why It Suits B2B Custom Display Sourcing

For B2B buyers, the most useful display pages are the ones that show real measurable value instead of generic marketing language. Here, the combination of UHD resolution, 3500 nits typical brightness, IPS wide viewing, 24/7 duty positioning, 50,000-hour backlight life, and retail-oriented application focus creates a more practical sourcing picture. It tells buyers that the panel is aimed at demanding commercial visibility projects, especially where direct sunlight, long operating hours, and storefront presentation all matter at the same time. That makes it a solid candidate for customized window-facing display systems and professional outdoor-adjacent retail signage solutions.

Share your target brightness, enclosure structure, installation orientation, and application environment to receive a tailored recommendation for your commercial signage project.

Application Scenarios

FAQ

What is the maximum brightness of this panel?

The panel supports configurable brightness from 500 nits up to 5000 nits depending on deployment requirements.

Is this panel suitable for direct sunlight environments?

Yes. The high-brightness configuration supports sunlight readable operation for outdoor-facing installations.

Does the panel support high refresh playback?

Yes. The display supports 120 Hz refresh operation with MEMC motion enhancement.

What interface does the panel use?

The panel uses a V-by-One 8-lane, 51-pin signal interface for UHD transmission.

What is the typical lead time for custom Mini LED display modules in quantities of 500-1000 units?

Lead time for custom Mini LED display modules depends on panel type, backlight configuration, and order volume. However, the exact lead time for the HS490ENT-N35 or any Mini LED variant is We recommend contacting our sales team with your specific requirements (e.g., brightness target, interface, mechanical dimensions) to receive a confirmed lead time and project timeline.

How do your gaming and laptop displays compare in terms of refresh rate, response time, and color gamut?

Our 49 Inch High Brightness LCD Panel (HS490ENT-N35) features a 120 Hz refresh rate, which is suitable for dynamic signage content. While this product is not designed for gaming or laptop applications, its IPS panel ensures consistent color and wide viewing angles. For gaming and laptop displays, we offer other models with higher refresh rates and faster response times. Please contact us with your specific requirements so we can recommend the appropriate product.

Do you offer displays with wide viewing angles (e.g., 85/85/85/85) for multi-user transportation information screens?

Yes, this display offers 89/89/89/89 viewing angles, exceeding the 85/85/85/85 requirement for multi-user transportation information screens. The IPS technology ensures consistent color and brightness from virtually any angle, making it ideal for public information displays in transit hubs, airports, and train stations. For further assurance, we can provide viewing angle measurement data upon request.

How do you ensure color consistency and calibration across multiple display units in a single production batch?

Color consistency across multiple units is achieved through rigorous factory calibration and binning of LED backlights and LCD cells. Each panel is tested to meet the specified 68% NTSC color gamut and 1.07 billion color support. For multi-unit installations, we recommend requesting a uniformity report or a sample matching service. Our engineering team can also discuss additional calibration options for your project.

Can you integrate touch controllers (resistive/capacitive) into custom display modules with specific firmware requirements?

Yes, touch integration is available as an optional feature for this display. We can support both resistive and capacitive touch controllers, and we can work with your specific firmware requirements. To proceed, please provide your touch controller specifications and firmware details so our engineers can evaluate compatibility and integration. A custom touch solution may require additional lead time for validation.

Can you customize the mechanical dimensions and mounting holes of a standard LCD panel to fit our specific enclosure design?

Mechanical customization, including mounting holes and enclosure fit, is possible for this LCD panel. The standard active area is 1073.8 × 604 mm, and we can adjust the bezel, mounting brackets, or hole patterns to match your design. Please share your enclosure drawings and mechanical constraints with our sales team. Customization may affect lead time and minimum order quantity, so early engagement is recommended.

Need a custom solution or samples?

Contact HuiSoar to discuss customized sunlight readable LCD panel solutions for transportation systems, smart city infrastructure, commercial digital signage, and high-brightness outdoor display projects. OEM and ODM engineering support is available for brightness customization, controller integration, enclosure development, and complete display-system solutions.
