58.5 Inch Android Bar LCD Display 3840×1080 for Passenger Information

3840×1080 High-Brightness Stretched Signage Display with Android 8.0 and VESA Mounting

A 58.5 Inch Android Bar LCD Display is a stretched digital signage solution for passenger information, semi-outdoor advertising, wayfinding, and commercial display systems. It combines a 58.5-inch panoramic format, 3840(RGB) × 1080 resolution, 41 PPI, 500–5000 nits brightness, Android 8.0 content support, and anti-glare haze 28%. With a 1428.48 × 401.76 mm active area, 11.8 kg weight, and 300 × 400 mm VESA mounting, it is designed for projects that need long-format content playback without building a signage system from a bare panel. The source page confirms the model, resolution, brightness range, Android 8.0 system, anti-glare surface, weight, and VESA mounting details.

At a Glance: 58.5-Inch Android Stretch Display Highlights

• 58.5-inch ultra-wide display format for panoramic route, advertising, and wayfinding content.
• 3840(RGB) × 1080 resolution with 41 PPI for detailed long-format signage layouts.
• 500–5000 nits luminance range for indoor, bright public, and semi-outdoor environments.
• Android 8.0 platform for content playback, scheduling, and signage-system deployment.
• Anti-glare haze 28% surface to reduce distracting reflections in public spaces.
• 1428.48 × 401.76 mm active area for long horizontal content zones.
• 11.8 kg weight and 300 × 400 mm VESA pattern for fixed wall or bracket mounting.

Product Overview of the 58.5 Inch Android Bar LCD Display

The 58.5 Inch Android Bar LCD Display is built for projects where a conventional 16:9 screen does not match the installation space or content layout. Passenger-information boards, corridor signage, retail guidance strips, advertising banners, and public-service displays often need a long horizontal field. A 3840×1080 stretched canvas allows route maps, arrival times, directional arrows, promotional messages, and status information to remain continuous instead of being split across multiple displays.

The product’s major distinction is that it is not just a raw open-cell panel. The source page lists Android 8.0, which makes the display more relevant for managed digital signage, scheduled playback, and commercial media deployment. For buyers, that can reduce system complexity compared with a component-only bar LCD that requires a separate media player, controller board, housing, and mounting architecture.

The display is best suited to transit and commercial buyers who need a large stretched display with high brightness and content-control capability. It should still be evaluated carefully for the final environment. Confirm the operating temperature requirement, front-glass design, enclosure protection, power input, network interface, media input method, and thermal path before approving samples or bulk installation.

Key Features of the 58.5 Inch Android Bar LCD Display

Technical Specifications of the 58.5-Inch Android Stretch Display

The readable source page lists operating temperature as 0 ~ 50°C and storage temperature as -20 ~ 60°C, while the user-supplied product screenshots/text list -20 ~ 70°C and -30 ~ 80°C. This should be treated as a required confirmation item before project approval.

Why Choose a 58.5-Inch Android Stretch Display for Public Information?

This product is strongest when a project needs both a panoramic display shape and integrated signage control.

3840×1080 Canvas for Multi-Zone Passenger Information

The 3840×1080 resolution gives signage designers room to divide the screen into logical zones: route direction, station name, service alert, advertising panel, and time/status information. In metro stations, railway platforms, and bus shelters, that wider canvas can reduce clutter compared with squeezing long timetable data into a standard rectangular monitor. The product page confirms the 3840(RGB) × 1080 resolution and 41 PPI specification.

Android 8.0 for Managed Digital Signage

Android 8.0 is valuable for signage projects that need playback, scheduling, or cloud-based content workflow. For transportation and retail deployments, the integrated system can simplify installation compared with a bare module plus external player. Engineering teams should still confirm software compatibility, file formats, network requirements, remote update workflow, and the exact external interfaces before final system design.

1428.48 mm Active Width for Continuous Visual Layouts

The 1428.48 mm active width gives the display a strong role in entrances, corridors, terminals, stations, and commercial buildings. Long text, arrows, maps, advertising banners, and queue information can be arranged in one panoramic line, which is the main reason to choose a stretched display rather than a standard 16:9 panel.

500–5000 Nits, Anti-Glare Haze 28%, and Wide Viewing

High brightness alone does not guarantee readability; glare and viewing angle matter as much in public spaces. This display combines a 500–5000 nits luminance range, 89-degree viewing in all four directions, and anti-glare haze 28%. The source page lists the brightness range, viewing angle, color support, and anti-glare surface treatment in the specification table.

For semi-outdoor advertising kiosks, mall entrances, stadium concourses, and bus shelter screens, select the brightness target according to ambient light, front glass, enclosure depth, and heat dissipation. If the final system uses protective glass, validate reflection control and optical stack performance before mass production.

VESA Mounting, 11.8 kg Structure, and Signage Integration

The mechanical profile is a major purchasing factor for this product. With 1444.08 mm width and 11.8 kg weight, bracket design and installation planning should begin early.

300 × 400 mm VESA Pattern for Fixed Deployment

The confirmed 300 × 400 mm VESA pattern supports wall-mounted or bracket-mounted signage installations. For transport hubs, shopping malls, and public buildings, verify wall strength, bracket rating, service clearance, cable access, and installation direction.

27.58 / 57.2 mm Depth for Enclosure Planning

The published physical size shows two depth references: 27.58 / 57.2 mm. Treat this as an engineering review item because rear electronics, back cover, connector clearance, or installation hardware may affect the real enclosure space. Request a mechanical drawing before cabinet production.

External Interfaces and Power Should Be Confirmed

The supplied text mentions USB, TF card, audio, RJ45, and DC input. Since the source table does not fully describe the external connector layout or power input value, confirm the interface board, power connector, network method, and cable exit direction before final procurement.

Recommended Applications for Large-Format Stretched Signage

Passenger information systems are a primary fit. Metro stations, railway platforms, and bus shelters can use the panoramic screen for arrival times, route status, emergency alerts, and advertising strips. The source page lists these passenger-information applications directly.

Semi-outdoor advertising is another strong use case. Shopping mall entrances, stadiums, and public commercial areas benefit from wide-format promotional content and high brightness. The product can also support digital menu boards, directional displays, factory dashboards, logistics monitoring, EV charging station displays, and long retail wayfinding screens when the installation is validated for brightness, mounting, power, and protection.

Customization Options for 58.5-Inch Android Display Projects

Project evaluation can include brightness target selection, Android signage software review, network/content workflow, interface board review, cover glass, anti-glare or anti-reflective treatment, optical bonding, enclosure adaptation, VESA bracket design, mounting hardware, thermal planning, packaging, and optional protective front structure. Touch is not confirmed in the supplied specification, so any touch requirement should be treated as a separate project-specific design.

Procurement and Engineering Checklist for 58.5-Inch Display Selection

• Confirm that 3840×1080 resolution fits the signage content layout.
• Select the correct brightness target within the 500–5000 nits range.
• Validate Android 8.0 software workflow, media playback, scheduling, and network needs.
• Confirm external interfaces, DC power input, cable exit, and service access.
• Review the 1444.08 × 420.36 mm physical size and 27.58 / 57.2 mm depth.
• Design mounting for 11.8 kg weight and 300 × 400 mm VESA structure.
• Confirm front glass, anti-glare performance, optical bonding, and enclosure protection.
• Resolve the operating-temperature conflict before sample sign-off.
