6.7 Inch MIPI IPS LCD Display with Capacitive Touch 2000 cd/m² 1920×1080

Download PDF

Product Gallery

Featured product image of 6.7 Inch MIPI IPS LCD Display with Capacitive Touch 2000 cd/m² 1920×1080, huisoar, HS670001B0, 6.7

Additional product image of 6.7 Inch MIPI IPS LCD Display with Capacitive Touch 2000 cd/m² 1920×1080, huisoar, HS670001B0

Key Specs

Model P/N

HS670001B0

Size

6.7″

Resolution

1920×1080

Brightness

2000 (Typ.)(cd/m²)

Viewing Angle

85/85/85/85 (L/R/U/D)

Connector Type

MIPI

Operating Temp

-30 ~

85 °C

Overall(mm)

156.22(W)×

99.28(H)×

4.76(D)

Upgrade Options (OEM/ODM)

huisoar

HS670001B0

General Features

Brand

huisoar

Panel Size (inch)

6.7"

Model P/N

HS670001B0

Resolution

1920×1080

Brightness (nits)

2000 cd/m² (Typ.)

Viewing Angle

85/85/85/85 (L/R/U/D)

Contrast Ratio

1200:1 (Typ.)

Response Time

Overall (mm)

156.22(W)×

99.28(H) ×

4.76(D) mm

Active Area (mm)

148.32 (W) × 83.43 (H) mm

Refresh Rate

60Hz

Display Colors

16.7M

Panel Type

tft-lcd

Connector Type

MIPI

Operating Temp

-30 ~

85 °C

Touchscreen Type

Capacitive Touch (G+G)

Storage Temp

-30 to 85 °C

Work Mode

N/A

Pixel Format

N/A

Touch Interface

N/A

Designed For

Outdoor Handheld Terminal Display

6.7 Inch 1920x1080 MIPI IPS LCD Display with Capacitive Touch 2000 cd/m²

The 6.7 inch MIPI IPS LCD display is designed for high-performance embedded systems requiring ultra-high brightness, precise touch interaction, and full viewing angle visibility. With a Full HD 1920×1080 resolution and up to 2000 cd/m² brightness, this display module ensures excellent readability even in direct sunlight environments.

Engineered with IPS technology and G+G capacitive touch integration, it is ideal for advanced control interfaces such as drone ground stations, industrial equipment, and outdoor smart terminals.

High Brightness 6.7 inch MIPI IPS LCD display for Outdoor Visibility

Sunlight Readable Performance

This 6.7 inch MIPI IPS LCD display delivers 2000 cd/m² brightness, making it highly suitable for outdoor and high-ambient-light applications. Compared to standard displays, it maintains clarity and contrast under direct sunlight.

IPS Wide Viewing Stability

With full viewing angles of 85° in all directions, the display ensures consistent color and image quality from any perspective, critical for shared-view or control panel environments.

Advanced Touch Integration of 6.7 inch MIPI IPS LCD display

G+G Capacitive Touch Technology

The integrated glass-glass capacitive touch panel enhances durability and touch precision. It supports smooth multi-touch interaction, ideal for human-machine interfaces.

Reliable Touch Controller

Equipped with ST1633I touch IC and IIC interface, the module ensures stable and responsive touch performance across industrial temperature ranges.

Industrial-Grade Design and Interface Flexibility

MIPI High-Speed Interface

The 6.7 inch MIPI IPS LCD display uses a 40-pin MIPI interface, enabling fast data transmission and compatibility with modern embedded processors.

Robust Environmental Performance

Operating from -30 to 85 °C, this display is engineered for harsh environments, including industrial automation, outdoor equipment, and UAV control systems.

Compact Mechanical Design

With a slim profile of 4.76 mm thickness and optimized structure, the module supports space-constrained product designs without compromising performance.

This 6.7 inch MIPI IPS LCD display combines ultra-high brightness, precise touch capability, and industrial durability, making it an excellent choice for demanding professional applications.

For customization options such as touch tuning, brightness adjustment, or interface adaptation, contact us for tailored display solutions.

Application Scenarios

FAQ

What is the minimum order quantity (MOQ) for custom display modules with integrated touch and controller boards?

For custom display modules with integrated touch and controller boards, the minimum order quantity (MOQ) typically starts at 500–1000 pieces for standard configurations, though lower MOQs may be negotiable for evaluation or prototyping. The exact MOQ for the HS670001B0 model with integrated touch and controller boards is not specified on this page; please contact Huisoar directly for a project-specific quote.

What is the minimum order quantity for custom display modules with specific connector types like 30-pin LVDS?

The minimum order quantity for custom display modules with specific connector types like 30-pin LVDS is not provided for this model. Generally, MOQs for connector customization depend on the complexity and volume; standard configurations may have MOQs of 500–1000 pieces, while custom connector pinouts or lengths may require higher minimums. For exact MOQ for the HS670001B0 with a 30-pin LVDS interface, please consult Huisoar.

What is your MOQ and sample policy for this model?

The MOQ and sample policy for the HS670001B0 are not explicitly stated on this page. Typically, for high-brightness industrial displays, MOQs range from 100 to 500 pieces for standard models, with samples available at a cost plus shipping. For this specific model, please contact Huisoar to confirm sample availability, lead time, and volume pricing.

Can you compare the power consumption and lifespan of your Mini LED backlight units against standard LED backlights in similar-sized panels?

The HS670001B0 uses a standard LED backlight, not Mini LED. For Mini LED backlight units, power consumption is generally 10–20% lower than standard LED backlights at equivalent brightness, and lifespan can exceed 50,000 hours due to reduced thermal stress. However, exact comparisons for this model are not available; please request specific data from Huisoar for Mini LED options.

What are the power consumption specifications for your high-brightness outdoor displays?

Power consumption specifications for the HS670001B0 are not listed on this page. For high-brightness outdoor displays of this size (6.7 inch, 2000 cd/m²), typical power consumption ranges from 5 to 10 watts for the backlight alone, depending on driving conditions. For exact figures, please contact Huisoar.

What is the typical lifespan (MTBF) of your industrial LCD panels under continuous operation?

The typical lifespan (MTBF) for the HS670001B0 is not provided. For industrial LCD panels of this class, MTBF is often rated at 30,000–50,000 hours under continuous operation at 25°C ambient. For this specific model, please request the MTBF report from Huisoar.

Can you provide high brightness displays with 1000+ nits that maintain performance in direct sunlight for outdoor industrial applications?

Yes, the HS670001B0 is a high-brightness display with 2000 cd/m², which exceeds 1000 nits and is designed for direct sunlight readability. Its IPS technology and 1200:1 contrast ratio further enhance outdoor performance. For other high-brightness models, please consult Huisoar's product line.

What are the vibration and shock resistance specifications for displays used in transportation and automotive environments?

Vibration and shock resistance specifications for the HS670001B0 are not listed. For transportation and automotive applications, displays typically require compliance with standards such as IEC 60068-2-6 (vibration) and IEC 60068-2-27 (shock). Please contact Huisoar to confirm if this model meets such requirements or if a ruggedized variant is available.

What is the minimum order quantity (MOQ) for custom TFT displays with specific touch screen integration?

The minimum order quantity for custom TFT displays with specific touch screen integration is not specified for the HS670001B0. Generally, MOQs for custom touch integration (e.g., G+G, optical bonding) start at 500–1000 pieces. For exact MOQ, please contact Huisoar.

What interface options (e.g., LVDS, eDP) are available for your 21.5-inch panels, and what are the pin configurations?

The HS670001B0 uses a MIPI interface, not LVDS or eDP. For 21.5-inch panels, Huisoar may offer LVDS, eDP, or other interfaces; pin configurations vary by model. Please consult Huisoar's product catalog or contact sales for specific 21.5-inch panel options and pinouts.

Freya Yang

[email protected]

+86 18318948097

Need a custom solution or samples?

6.7 Inch MIPI IPS LCD Display for Outdoor Handheld Terminals Need a sunlight-readable touch display for rugged handheld or outdoor control equipment? This 6.7 inch MIPI IPS LCD display combines Full HD 1920×1080 resolution, 2000 cd/m² typical brightness, IPS wide viewing angles, and G+G capacitive touch to deliver clear visibility and responsive operation in demanding field environments. With a 40-pin MIPI interface, 1200:1 contrast ratio, ST1633I touch IC, IIC touch interface, 60Hz refresh rate, 16.7M colors, slim 4.76mm structure, and a wide -30°C to 85°C operating temperature range, it is well suited for outdoor handheld terminals, drone ground stations, UAV control systems, industrial automation equipment, outdoor smart terminals, and rugged embedded control devices. Request the datasheet or sample today to verify sunlight readability, MIPI interface compatibility, touch performance, mechanical dimensions, and OEM/ODM options such as brightness tuning, PCAP or resistive touch, cover lens, optical bonding, custom cables, driver board support, wide-temperature reinforcement, labeling, packaging, and documentation support.
