Industrial 17.3 Inch TFT LCD Module with 800 Nits Brightness
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS173GA01-C080
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Display Colors
Panel Type
Connector Type
Surface Treatment
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Pixel Format
Designed For
Full HD industrial IPS TFT LCD module with LVDS interface, sunlight-readable 800 nits brightness, and stable operation for outdoor digital signage and industrial equipment.
Industrial 17.3 Inch TFT LCD Module for Outdoor and Digital Signage Systems
Outdoor industrial displays require much more than standard consumer-grade LCD performance. Sunlight visibility, stable signal transmission, long-term durability, and Full HD image clarity are essential for industrial control systems, digital signage, and outdoor information terminals operating continuously in demanding environments.
This Industrial 17.3 Inch TFT LCD Module is engineered specifically for those requirements. Combining 1920×1080 Full HD resolution, 800 nits high brightness, IPS viewing technology, and LVDS signal stability, the module provides reliable display performance for industrial OEM equipment and outdoor display integration projects.
Its robust structure and industrial-grade environmental specifications make it suitable for 24/7 commercial and industrial operation.
Industrial 17.3 Inch TFT LCD Module with Full HD Resolution
The module features a 17.3-inch a-Si TFT-LCD panel with Full HD 1920×1080 resolution. The 16:9 widescreen format supports modern multimedia interfaces, industrial monitoring systems, and high-definition advertising content.
For industrial applications, Full HD resolution improves:
- Data visualization accuracy
- Graphical interface clarity
- Multi-window operation
- Industrial dashboard readability
- Video playback quality
- Monitoring system precision
The IPS hard screen structure further improves image consistency and visual stability across wider viewing positions, helping operators maintain readability from multiple angles.
800 Nits High Brightness for Outdoor Visibility
One of the core advantages of this Industrial 17.3 Inch TFT LCD Module is its 800 cd/m² high brightness performance.
Conventional indoor TFT modules typically operate at 250–400 nits brightness levels, which become difficult to read under strong ambient lighting or direct sunlight. This module is specifically optimized for sunlight-readable operation in outdoor environments.
The high-brightness WLED backlight system supports:
- Outdoor advertising kiosks
- Public information terminals
- Smart transportation systems
- Industrial control panels
- Semi-outdoor HMI systems
- Retail digital signage
- Smart city infrastructure
The anti-glare surface treatment additionally reduces reflective interference from sunlight and overhead industrial lighting.
IPS Wide Viewing Technology
The display uses IPS hard screen technology to deliver stable image quality and wide-angle visibility.
Typical viewing specifications include:
- Left/Right: 80°
- Up/Down: 60°/80°
- CR≥10 viewing standard
Wide viewing performance is particularly important for:
- Public display systems
- Multi-user industrial stations
- Advertising displays
- Transportation terminals
- Interactive information systems
This ensures displayed information remains readable even when viewed from off-center positions.
LVDS Interface for Stable Industrial Signal Transmission
The module uses a 30-pin LVDS interface for stable high-speed signal communication.
LVDS technology is widely adopted in industrial embedded systems because of its advantages:
- Reduced electromagnetic interference
- Long-distance signal stability
- Lower power consumption
- Reliable high-speed data transfer
- Improved industrial compatibility
For industrial integrators and OEM system designers, LVDS simplifies integration with industrial motherboards, embedded controllers, and digital signage processors.
Rugged Mechanical Design for Industrial Integration
The module features a compact but durable mechanical structure with dimensions of 403 × 240 × 13 mm.
The active display area measures 381.888 × 214.812 mm, offering a balanced screen size suitable for medium-format industrial equipment and outdoor signage systems.
The industrial-grade design supports:
- Continuous operation
- Structural stability
- Long-term outdoor deployment
- Industrial enclosure integration
- Advertising machine installation
Its flat rectangular form factor also simplifies custom housing integration for OEM projects.
Industrial Environmental Reliability
Industrial displays must maintain stable operation across varying temperatures and environmental conditions.
This module supports:
- Operating temperature: 0°C to 70°C
- Storage temperature: -20°C to 70°C
The wide operating range supports deployment in:
- Outdoor kiosks
- Factory automation systems
- Smart retail equipment
- Industrial monitoring systems
- Transportation terminals
- Public infrastructure displays
The WLED backlight system additionally offers a service life exceeding 50,000 hours, reducing maintenance frequency and long-term operating costs.
OEM and Customization Support
Industrial display projects frequently require customization for mechanical, optical, and electrical integration.
This Industrial 17.3 Inch TFT LCD Module supports OEM customization options including:
- Brightness customization
- Touch panel integration
- Driver board development
- Optical bonding
- Interface adaptation
- Cover glass customization
- Mechanical redesign
- Open frame integration
These customization services help OEM customers accelerate product development and simplify industrial deployment.
FAQ
Is this Industrial 17.3 Inch TFT LCD Module suitable for outdoor use?
What applications is this display designed for?
Can brightness or touch functions be customized?
What is the typical lead time and production capacity?
Lead time and production capacity are For accurate information, please contact our sales team with your volume requirements and target delivery date. We will provide a tailored schedule and capacity commitment.
How does the operating temperature range of your industrial panels (e.g., -30°C to 80°C) affect long-term performance and warranty?
The operating temperature range for this model is 0°C to 70°C (storage -20°C to 70°C). For extended ranges like -30°C to 80°C, please confirm with our engineering team; we can evaluate custom solutions for your application. Warranty terms are typically based on the specified range.
What is the typical refresh rate and response time of your industrial TFT panels for motion graphics or video playback in HMIs?
This module has a 60 Hz refresh rate. Response time is
What is the operating temperature range for your outdoor high-brightness displays, and do you offer extended ranges?
The operating temperature range for this outdoor high-brightness display is 0°C to 70°C (storage -20°C to 70°C). Extended ranges are
What are the available interface options (e.g., LVDS, eDP) and connector types for your industrial LCD panels, and do you offer compatible controller boards or driver solutions?
This module uses an LVDS interface with a 30-pin connector. Compatible controller boards or driver solutions are
Do you offer displays with In-Cell touch technology that are suitable for automotive dashboards or industrial HMIs with high reliability?
This model is listed as 'Without Touch'. In-Cell touch technology is not offered on this page; for automotive or industrial HMI applications requiring high-reliability touch, please consult our sales team for alternative options.
Can you customize the mechanical dimensions and mounting holes of a standard LCD panel to fit our specific enclosure design?
Custom mechanical dimensions and mounting holes are Please provide your enclosure design specifications to our engineering team; we will assess feasibility and provide a custom solution if possible.
