24 Inch HMI Touch LCD Module 1000 Nits IP65 Industrial Display
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS24A1609V1
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Display Colors
Panel Type
Connector Type
Surface Treatment
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Touch Interface
Designed For
Rugged Full HD PCAP Touch Display with 1000 Nits Brightness, IP65 Front Protection, and LVDS Signal Input
24 Inch HMI Touch LCD Module is designed for industrial control systems where operators need clear visual feedback, fast touch response, and stable long-term operation. In factory automation, outdoor terminals, medical equipment, and equipment monitoring panels, a display is not just a screen; it is the daily operating interface between the user and the machine.
This module combines a 24 inch Full HD TFT LCD panel, 1000 nits high brightness, capacitive multi-touch, and IP65 front protection. For buyers building HMI terminals, industrial dashboards, or outdoor equipment interfaces, the main procurement value is its balance of readability, touch usability, and rugged front-side protection.
24 Inch HMI Touch LCD Module with Full HD Visibility
The 1920 × 1080 resolution provides enough detail for control menus, warning messages, live data, and multi-zone HMI layouts. With an active area of 531.36 × 298.89 mm, the display gives equipment designers a large visual surface while keeping the standard 16:9 interface format used in many industrial control systems.
The 1000 nits brightness improves readability in bright workshops, semi-outdoor installations, and outdoor terminal housings. Compared with standard low-brightness HMI displays, this brightness level gives stronger visibility when the screen is exposed to ambient light, factory lighting, or daylight through protective glass.
A wide 89/89/89/89 viewing angle supports multi-position operation. This is useful when the display is installed on control cabinets, production line equipment, diagnostic systems, or shared workstations where operators may view the screen from different directions.
Industrial Touch Performance for Daily Operation
The capacitive multi-touch function supports intuitive interaction for industrial HMI software. Operators can use familiar gestures for menu navigation, parameter adjustment, page switching, and status checking. The USB touch interface supports straightforward integration, while I2C and RS232 options provide additional flexibility for embedded control systems.
The 6–8 ms response time helps reduce visual lag during operation. For HMI applications, this matters because delayed display feedback can affect operator confidence, especially during alarm handling, equipment setup, or real-time monitoring.
The touch structure is suitable for industrial automation, medical equipment, and outdoor terminal use. For projects that need custom cover glass, logo printing, interface changes, or controller adaptation, the product can be positioned as a customized industrial touch display platform rather than a fixed consumer-grade screen.
IP65 Front Protection for Harsh Environments
The IP65 front design helps protect the user-facing side against dust and water spray. This is important for workshops, outdoor terminals, food-related industrial areas, public operation panels, and environments where accidental splashing or dust exposure is common.
The anti-glare and anti-fingerprint surface treatment also improves usability. Anti-glare treatment reduces reflection from overhead lighting or sunlight, while anti-fingerprint treatment helps maintain a cleaner viewing surface during frequent operation.
The WLED backlight with a rated lifetime of at least 50,000 hours supports long-term use in industrial equipment. For procurement teams, long backlight life can reduce maintenance frequency and improve the total cost of ownership.
LVDS Interface and Integration Considerations
The module uses an LVDS connector type, which is widely adopted in industrial display systems because of stable signal transmission and mature controller board support. For HMI equipment manufacturers, LVDS can simplify pairing with embedded boards, industrial PCs, and custom controller platforms.
The product data currently lists the input voltage as N/A, so engineering confirmation is required before electrical design finalization. Buyers should verify power input, connector pin assignment, mechanical drawing, and touch controller details before mass production.
Recommended Uses for 24 Inch HMI Touch LCD Module
This module is suitable for industrial HMI panels, automation control cabinets, medical equipment displays, outdoor self-service terminals, production line monitoring systems, and rugged information terminals. It is especially appropriate when the project requires a larger touch interface, better daylight readability, and a protected front surface.
For outdoor terminals, the 1000 nits brightness, IP65 front protection, and anti-glare surface create a practical combination. For factory automation, the Full HD resolution, capacitive touch, and LVDS interface help support modern HMI software layouts.
FAQ
What should be confirmed before mass production?
Is this 24 Inch HMI Touch LCD Module suitable for outdoor use?
What touch technology does it use?
Does it support industrial HMI applications?
Can the module be customized?
What is the minimum order quantity (MOQ) for custom TFT displays with specific touch screen integration?
For custom TFT displays with specific touch screen integration, MOQ is typically determined by panel availability, customization complexity, and production batch size. Standard industry practice for industrial HMI modules often requires an MOQ ranging from dozens to hundreds of units, depending on the level of customization (e.g., optical bonding, cover glass changes, interface modifications). To obtain the exact MOQ for your project, please contact our sales team with your target volume and customization requirements.
Can you provide high brightness displays with 1000+ nits that maintain performance in direct sunlight for outdoor industrial applications?
Yes, this 24 Inch HMI Touch LCD Module offers 1000 nits brightness, which is suitable for direct sunlight readability in outdoor industrial applications. The high brightness level ensures clear visibility even under strong ambient light. For applications requiring even higher brightness, please contact our engineering team to discuss custom options. We recommend evaluating this module in your specific lighting environment to confirm performance.
What are the operating temperature ranges for your industrial-grade LCD panels?
This industrial-grade LCD panel has an operating temperature range of -20°C to 70°C and a storage temperature range of -30°C to 85°C. These ranges are suitable for most industrial environments, including factory floors and outdoor terminals. For extreme temperature conditions beyond these limits, please consult with our engineering team to explore possible custom solutions or additional thermal management options.
Do you offer displays with wide viewing angles (e.g., 85/85/85/85)?
Yes, this display offers wide viewing angles of 89/89/89/89 degrees (left/right/up/down), which exceeds the common 85/85/85/85 specification. This ensures consistent image quality and color accuracy from virtually any viewing direction, making it ideal for HMI panels that need to be readable from multiple positions. For applications requiring even wider angles, please confirm with our engineering team.
What touch screen technologies do you support (e.g., capacitive, resistive, in-cell)?
This 24 Inch HMI Touch LCD Module (HS24A1609V1) integrates a capacitive multi-touch panel, as specified in the product information. Capacitive touch is the standard technology for this model, offering multi-touch support suitable for industrial HMI applications.
