32 Inch High Brightness Industrial LCD Module Wide Temperature
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS320GB01-C150
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Display Colors
Panel Type
Connector Type
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Designed For
Industrial IPS Display Solution with 1500-Nit Brightness and Full HD Performance
32 Inch High Brightness Industrial LCD Module for Outdoor Equipment
The 32 Inch High Brightness Industrial LCD Module is designed for equipment manufacturers that require reliable visibility in outdoor and industrial environments. Many conventional LCD panels struggle when exposed to direct sunlight or changing temperatures, leading to poor readability and reduced operational efficiency. This module addresses those challenges through a powerful 1500-nit backlight system, IPS viewing technology, and wide temperature support, making it suitable for demanding commercial and industrial deployments.
High Brightness Performance for Sunlight Readability
One of the biggest challenges for industrial displays is maintaining visibility under strong ambient light. With a typical brightness of 1500 cd/m², this module provides significantly higher luminance than standard commercial displays.
The enhanced brightness allows operators and end users to view information clearly in transportation terminals, outdoor kiosks, industrial control systems, and public information displays.
Key benefits include:
- Improved outdoor readability
- Better content visibility
- Reduced image washout
- Enhanced user experience
- Reliable daytime performance
IPS Technology Delivers Wide Viewing Angles
Why IPS Matters for Industrial Applications
The module uses IPS hard-screen technology to provide consistent image quality from virtually any viewing position.
With viewing angles reaching 89 degrees in all directions, displayed content remains clear and accurate even when viewed from the side. This characteristic is particularly valuable for public-facing systems and multi-user industrial environments.
Advantages include:
- Stable color reproduction
- Wide viewing performance
- Improved image consistency
- Better readability in public installations
Wide Temperature Reliability for Industrial Deployment
Industrial equipment often operates in harsh environments where temperature fluctuations can affect display performance.
The 32 Inch High Brightness Industrial LCD Module supports operation from -20°C to 70°C, helping manufacturers deploy equipment across a wide range of climates and operating conditions.
Typical deployment environments include:
- Industrial automation systems
- Outdoor transportation terminals
- Factory monitoring stations
- Smart city infrastructure
- Energy and utility equipment
This wide-temperature capability contributes to long-term system stability and reliability.
LVDS Interface Simplifies Integration
The display utilizes a standard LVDS interface with a 51-pin connection architecture.
LVDS remains one of the most widely adopted industrial display interfaces because it provides:
- Stable signal transmission
- Low electromagnetic interference
- Broad controller compatibility
- Reliable long-distance signaling
This makes the module suitable for integration with industrial PCs, ARM-based systems, embedded controllers, and custom hardware platforms.
Typical Applications
Industrial Control Equipment
Operator panels, machine interfaces, and process monitoring systems.
Outdoor Information Displays
Public information terminals and wayfinding systems.
Transportation Systems
Passenger information displays and ticketing terminals.
Digital Signage Platforms
Commercial advertising and communication systems requiring sunlight-readable performance.
Smart City Solutions
Urban communication infrastructure and public service terminals.
FAQ
Can the module be integrated into custom equipment?
Is this module suitable for direct sunlight?
Does the display support industrial temperature ranges?
What interface does the module use?
What is the typical lead time and production capacity?
Lead time and production capacity depend on order volume, configuration, and current factory load. Production capacity is subject to material availability and scheduling. To obtain an accurate lead time and capacity commitment for your specific quantity and customization needs, please contact our sales team with your requirements. We will provide a confirmed timeline and capacity plan upon request.
What touch screen technologies do you support (e.g., capacitive, resistive, in-cell)?
This module supports optional touch functionality. We can integrate capacitive or resistive touch panels based on your application requirements. Capacitive touch is recommended for multi-touch and outdoor use, while resistive touch is suitable for gloved or stylus operation. Please specify your touch preference and environmental conditions for a tailored solution.
What are the key durability and reliability differences between your standard TFT displays and your sunlight readable models for outdoor industrial use?
The primary difference lies in brightness and temperature tolerance. Additionally, this module supports an operating temperature range of -20°C to 70°C and a storage range of -30°C to 80°C, which is wider than many standard displays. It also uses IPS technology with 89/89/89/89 viewing angles and a 1200:1 contrast ratio, ensuring consistent image quality under harsh lighting. For specific reliability test data (e.g., MTBF, vibration/shock ratings), please request the full datasheet.
What is the typical response time and refresh rate for your industrial TFT displays?
The refresh rate for this 32-inch industrial TFT LCD module is 60 Hz, which is standard for most industrial and commercial applications.
Can you customize the display driver board to match our existing system's LVDS or eDP interface?
Yes, customization of the driver board is possible to match your system's interface requirements. This module natively supports LVDS interface. Customization may involve changes to the timing controller, connector pinout, or power supply specifications. Please provide your system's interface details, voltage levels, and mechanical constraints. Our engineering team will assess feasibility and provide a solution. Note that custom driver board development may affect lead time and minimum order quantity; these details will be confirmed upon request.
Can you customize the mechanical dimensions and mounting holes for a specific industrial enclosure?
Yes, we can customize mechanical dimensions and mounting holes to fit your specific industrial enclosure. This includes adjusting the active area position, bezel size, and hole patterns. Please provide your enclosure drawings or mechanical requirements, and our engineering team will evaluate feasibility and provide a custom design proposal.
