7 Inch MIPI IPS TFT LCD Display 720×1440 for Smart Home Panels

Download PDF

Product Gallery

Featured product image of 7 Inch MIPI IPS TFT LCD Display 720×1440 for Smart Home Panels, huisoar, HS700185B0, 7 inch MIPI

Additional product image of 7 Inch MIPI IPS TFT LCD Display 720×1440 for Smart Home Panels, huisoar, HS700185B0, 7 inch MIPI

Key Specs

Model P/N

HS700185B0

Size

6.9″

Resolution

720×1440

Brightness

300 (Typ.)(cd/m²)

Viewing Angle

85/85/85/85

Connector Type

N/A

Operating Temp

-20 ~

70 °C

Overall(mm)

80.21(W)×

162.34(H)×

2.32(D)

Upgrade Options (OEM/ODM)

huisoar

HS700185B0

General Features

Brand

huisoar

Panel Size (inch)

6.9"

Model P/N

HS700185B0

Resolution

720×1440

Brightness (nits)

300 cd/m² (Typ.)

Viewing Angle

85/85/85/85

Contrast Ratio

1200:1

Response Time

Overall (mm)

80.21(W)×

162.34(H) ×

2.32(D) mm

Active Area (mm)

78.02 × 156.04 mm

Refresh Rate

60Hz

Bezel Opening

N/A

Display Colors

16.7M

Panel Type

tft-lcd

Connector Type

N/A

Surface Treatment

N/A

Operating Temp

-20 ~

70 °C

Touchscreen Type

optional

Storage Temp

-30 ~ 80°C

Work Mode

IPS, Transmissive

Pixel Format

N/A

Input Voltage (V)

5.5

Touch Interface

optional

Designed For

Smart home panels, handheld devices, MP3/PMP, home appliances, medical devices

7 Inch MIPI IPS TFT LCD Display 720x1440 for Smart Home Panels

This 7 inch MIPI IPS TFT LCD display is designed for compact smart home panels, handheld terminals, portable media devices, and embedded control interfaces that require a slim portrait-format screen. With 720 × 1440 resolution, IPS full-viewing performance, and a 30-pin MIPI 4 Lane interface, it provides a practical display platform for products where visual clarity, compact mechanical fit, and modern UI presentation are important.

Why This 7 Inch MIPI IPS TFT LCD Display Fits Smart Panels

Portrait Resolution for Modern Interface Layouts

The 720 × 1440 pixel structure gives this display a tall portrait layout, making it suitable for smart home dashboards, scene control menus, room status panels, and handheld interface systems. Compared with lower-resolution 7-inch modules, this screen supports sharper icons, clearer text, and more refined UI layouts.

Slim Mechanical Structure

The module has an outline size of 80.21 × 162.34 × 2.22 mm, helping designers build thinner front panels and compact embedded devices. Its active area of 78.02 × 156.04 mm provides an efficient viewing region while keeping the overall footprint narrow enough for smart control products and portable terminals.

Technical Value for Embedded Display Integration

MIPI 4 Lane Interface with 30-Pin Connection

The MIPI 4 Lane interface supports high-speed display signal transmission for compact embedded systems. A 30-pin connection helps reduce connector space while maintaining practical integration flexibility for product developers working on smart home hardware, portable media systems, or medical display terminals.

IPS Full Viewing Angle Performance

With 85/85/85/85 viewing angle performance, this 7 inch MIPI IPS TFT LCD display maintains stable visibility from different viewing positions. This is useful for wall-mounted panels, tabletop controllers, and handheld devices where users may view the display from changing angles during daily operation.

300 Nits Brightness for Indoor Applications

The 300 nits brightness level is suitable for indoor environments such as smart home rooms, handheld devices, control panels, medical terminals, and home appliance interfaces. It provides readable display performance without positioning the module as an outdoor or sunlight-readable product.

Application Scenarios

This display is suitable for smart home control panels, MP3/PMP devices, handheld terminals, home appliances, medical devices, and compact industrial interfaces. Its portrait format supports app-like UI layouts, icon-based dashboards, and vertically arranged menus, making it a strong option for products that need a refined visual interface in a narrow space.

For projects requiring a slim portrait display with MIPI interface, IPS viewing performance, and 720 × 1440 resolution, this 7 inch MIPI IPS TFT LCD display offers a practical balance of image quality, integration flexibility, and compact mechanical design. Contact HuiSoar to discuss display selection, interface matching, touch customization options, and OEM/ODM project support.

Application Scenarios

FAQ

What is the minimum order quantity (MOQ) for custom display modules with specific touch interfaces?

For custom display modules with specific touch interfaces, the minimum order quantity (MOQ) typically starts at 500 to 1,000 pieces for standard modifications like adding a capacitive touch panel or adjusting the cover glass. For fully custom touch solutions, such as integrating a specific touch controller or optical bonding, MOQs may be higher, often 1,000 to 3,000 pieces. The exact MOQ for the HS700185B0 with a custom touch interface is not listed on the page; please contact Huisoar directly to confirm the minimum quantity for your specific touch requirements.

What is the minimum order quantity (MOQ) for custom-sized automotive-grade displays with capacitive touch, like the 12.3" model shown?

The page does not provide information on a 12.3-inch model or automotive-grade displays. For custom-sized automotive-grade displays with capacitive touch, MOQs generally range from 1,000 to 5,000 pieces, depending on the level of customization, such as optical bonding, cover glass shape, and AEC-Q100 compliance. Automotive projects often require higher volumes due to validation costs. For the HS700185B0, which is not specified as automotive-grade, please inquire with Huisoar about any automotive variants or custom options.

What is the typical lead time and production capacity?

Typical lead times for standard TFT LCD modules like the HS700185B0 are 4 to 8 weeks for sample quantities and 8 to 12 weeks for production orders, depending on order volume and component availability. Production capacity varies by factory; for this model, standard capacity is usually several thousand pieces per month. Exact lead times and capacity for the HS700185B0 are not stated on the page; please contact Huisoar for current estimates based on your order size and schedule.

What are the brightness levels available for industrial displays, and can you customize beyond 1500 nits?

The HS700185B0 is specified with a brightness of 300 nits, which is typical for indoor smart home panels. For industrial displays, brightness levels commonly range from 300 to 1,500 nits, with high-brightness options (e.g., 1,000 nits or more) available for outdoor or sunlight-readable applications. Customization beyond 1500 nits is possible but may require optical enhancements like higher-brightness backlights or optical bonding, which can affect cost and lead time. The page does not list higher brightness options for this model; please confirm customization feasibility with Huisoar.

What are the lead times for custom-sized LCD panels in transportation smart display applications?

For custom-sized LCD panels in transportation smart display applications, lead times typically range from 10 to 16 weeks, depending on the complexity of customization, such as custom resolution, interface, or optical bonding. The HS700185B0 is not specified for transportation use; its standard lead time is likely 8 to 12 weeks for production. Exact lead times for custom transportation displays should be discussed with Huisoar, as they depend on design validation, tooling, and component sourcing.

What are the differences between your standard industrial panels and military rugged displays in terms of construction?

Standard industrial panels like the HS700185B0 use a TFT-LCD structure with a standard backlight, polarizer, and optional touch layer, designed for indoor environments. Military rugged displays typically feature reinforced construction, including metal frames, thicker cover glass, optical bonding for sunlight readability, wider temperature ranges (e.g., -40°C to +85°C), and enhanced shock/vibration resistance. The HS700185B0 has an operating temperature of -20°C to +70°C and is not ruggedized. For rugged applications, custom designs with additional mechanical and optical treatments are required.

Can you provide datasheet, drawing, and pin definition?

Yes, Huisoar can provide a datasheet, mechanical drawing, and pin definition for the HS700185B0 upon request. These documents typically include the active area dimensions (78.02 × 156.04 mm), interface details (30-pin MIPI 4-lane), electrical characteristics (5.5V), and optical specifications. The page does not include a direct download link; please contact Huisoar's sales or technical support to obtain the complete documentation package.

Can you provide samples for testing before placing a bulk order, and what are the terms?

Yes, samples of the HS700185B0 are typically available for testing before bulk orders. Sample terms usually require payment of the unit price plus shipping, with a lead time of 1 to 2 weeks for standard samples. For custom versions (e.g., with touch), sample lead times may be longer. The page does not specify sample pricing or availability; please contact Huisoar to arrange samples and confirm terms, including any minimum sample quantity or refund policies.

Can you supply displays with specific certifications for automotive (AEC-Q100) or medical (ISO 13485) applications, and what are the cost implications?

The HS700185B0 is not listed with specific automotive (AEC-Q100) or medical (ISO 13485) certifications. For such applications, displays typically require additional design and testing to meet these standards, which can increase unit cost by 20-50% or more due to rigorous validation, component selection, and documentation. Huisoar may offer certified variants or support custom certification projects. Please inquire directly about certification options and cost implications for your target application.

What is the typical lead time for custom display modules with specific interface requirements?

For custom display modules with specific interface requirements, typical lead times range from 8 to 14 weeks, depending on the complexity of interface changes (e.g., adding a different MIPI configuration, LVDS, or RGB interface) and the need for new PCB design or firmware. The HS700185B0 uses a standard 30-pin MIPI 4-lane interface; custom interface modifications would require engineering evaluation. Exact lead times are not provided on the page; contact Huisoar for a project-specific timeline.
