18.5 Inch High Brightness LCD Panel 1500 Nits LVDS Display
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS185ENT-GE15
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Display Colors
Panel Type
Connector Type
Surface Treatment
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Input Voltage (V)
Weight (g)
Designed For
Sunlight-readable 18.5-inch S-IPS TFT-LCD panel with configurable brightness up to 1500 nits, LVDS interface, and industrial-grade reliability.
18.5 Inch High Brightness LCD Panel solutions are widely used in industrial equipment, information kiosks, advertising displays, and embedded systems where visibility, reliability, and long-term operational stability are essential. Traditional commercial displays often struggle to maintain image clarity in bright environments, especially when exposed to sunlight or high ambient lighting. This industrial-grade panel addresses those challenges with configurable brightness levels up to 1500 nits and advanced S-IPS display technology.
Optimized Visibility for Bright Environments
The panel features a WXGA resolution of 1366 × 768 and a brightness range from 500 to 1500 nits. This flexibility allows manufacturers and system integrators to select the appropriate brightness level for indoor, semi-outdoor, or sunlight-readable applications.
Compared with conventional displays operating at 250–350 nits, the high-brightness configuration delivers significantly improved readability in transportation hubs, retail environments, industrial facilities, and public information systems.
The anti-glare surface treatment with 13% haze further enhances visibility by reducing reflections and minimizing glare from ambient lighting sources.
S-IPS Technology for Wide Viewing Performance
This panel utilizes S-IPS technology in a normally black transmissive display structure. The result is excellent color consistency and image quality across wide viewing angles.
With a full viewing angle specification of 89° in all directions, operators and viewers can clearly see content from multiple positions without significant color shifting or contrast degradation.
These characteristics are especially valuable for:
- Information display systems
- Self-service kiosks
- Industrial control stations
- Digital signage networks
- Transportation information boards
Reliable Industrial-Grade Design
Industrial deployments require dependable operation over extended periods. This display incorporates a robust WLED backlight system with a rated service life of approximately 50,000 hours.
The integrated LED driver design simplifies system integration while helping manufacturers reduce overall system complexity.
Operating temperature support from -20°C to 70°C allows deployment in demanding environments where temperature fluctuations can affect standard commercial displays.
Storage temperature support extends from -30°C to 80°C, providing additional reliability during transportation and long-term inventory storage.
LVDS Interface for Easy Integration
The display incorporates a standard 30-pin LVDS interface operating on a 5V power supply.
LVDS remains one of the most widely used interfaces in industrial electronics due to:
- Stable signal transmission
- Low electromagnetic interference
- Excellent compatibility
- Reliable long-distance data communication
- Industrial controller support
This makes the panel suitable for integration into existing industrial and embedded system architectures.
Flexible Brightness Options
Unlike fixed-brightness displays, this panel is available in multiple brightness configurations:
- HS185ENT-GE05 — 500 nits
- HS185ENT-GE10 — 1000 nits
- HS185ENT-GE15 — 1500 nits
This flexibility enables OEMs to optimize system cost and performance according to project requirements.
Common Application Scenarios
The panel is designed for a broad range of commercial and industrial applications:
Industrial Monitors
Used in factory automation, machine interfaces, and process monitoring systems where reliability is critical.
Information Displays
Suitable for public transportation systems, building directories, and information terminals.
Digital Signage
The high-brightness configuration supports advertising and promotional displays in bright environments.
Embedded Systems
The compact structure and LVDS interface make the panel ideal for embedded equipment requiring stable display performance.
Self-Service Kiosks
Commonly integrated into ticketing systems, payment terminals, and customer service stations.
OEM and Customization Support
Manufacturers frequently require customized display solutions. This panel supports a variety of OEM and ODM services including:
- Brightness customization
- Touchscreen integration
- Cover glass modification
- Driver board development
- Mechanical customization
- Branding services
These capabilities help reduce development time while providing flexibility for specialized applications.
FAQ
What is the maximum brightness available?
What interface does the panel use?
Is this panel suitable for outdoor use?
What is the backlight lifetime?
Does the panel support wide viewing angles?
Can OEM customization be provided?
Can you provide samples for testing before placing a bulk order, and what are the terms?
Yes, samples are typically available for evaluation before bulk orders. Please contact our sales team to discuss sample quantity, lead time, and any associated costs. We can provide a sample unit of the HS185ENT-GE15 for testing in your application. Terms such as sample fee, shipping, and return policy will be confirmed upon request.
Can you provide detailed specifications for sunlight readable displays, including typical brightness (nits), contrast ratio, and optical bonding options for outdoor or high-ambient-light use?
This sunlight-readable panel offers a typical brightness of 1500 nits and a contrast ratio of 1000:1 (Typ.). It uses S-IPS technology for wide viewing angles (89/89/89/89°). Optical bonding is an optional enhancement to reduce glare and improve durability in outdoor or high-ambient-light environments. For detailed specifications on bonding options and their impact on optical performance, please request the datasheet or confirm with our engineering team.
Can you customize the display driver board to match our existing system's LVDS or eDP interface?
Yes, the HS185ENT-GE15 panel uses a standard 30-Pin LVDS (1 Channel, 8-bit) interface, which is widely compatible with many industrial driver boards. For exact customization options, including specific board models, lead times, and interface adaptation, please contact our engineering team with your system specifications. We will confirm feasibility and provide a tailored solution based on your project needs.
Can you integrate capacitive or resistive touch screens with optically bonded covers for enhanced durability?
Yes, capacitive or resistive touch screens can be integrated with this panel. Optical bonding is available as an option to enhance durability, reduce reflections, and improve sunlight readability. The touch solution can be customized to your application requirements. Please specify your preferred touch type and any environmental or durability needs. Our team will provide a tailored solution and confirm compatibility with the HS185ENT-GE15.
