23.8 Inch Outdoor High Nits Kiosk LCD Module Manufacturer
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS238ENT-NE10
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Bezel Opening
Display Colors
Panel Type
Connector Type
Surface Treatment
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Pixel Format
Input Voltage (V)
Weight (g)
Operating Environment
Designed For
23.8 Inch Outdoor High Nits Kiosk LCD Module Manufacturer
The Outdoor High Nits Kiosk LCD Module combines a 23.8-inch FHD IPS image, selected 1000 cd/m² output and 30-pin LVDS for OEM integration.
Product Summary
The Outdoor High Nits Kiosk LCD Module is designed for equipment builders that need a familiar 23.8-inch format, stronger visibility than a standard indoor panel and module-level control over the final enclosure. Its 1920 × 1080 image provides sufficient area for kiosk menus, public information, industrial interfaces and commercial-terminal workflows without moving into an oversized signage format.
The selected configuration uses a fixed 1000 cd/m² grade within a broader product family. IPS normally-black transmissive operation, 89° viewing in each listed direction and an anti-glare 3H surface help support readable text and interface content from different user positions. The 527.04 × 296.46 mm active area provides the usable image canvas, while the 530.2 × 299.6 mm viewing area supports front-window planning.
A selected luminance value does not by itself guarantee finished-system sunlight readability.
A matching 30-pin connector does not prove LVDS compatibility.
The standard panel rate is 75 Hz; higher-frame wording requires configuration-specific confirmation.
Key Specifications
| Parameter | Confirmed value |
|---|---|
| Screen diagonal | 23.8 inches |
| Resolution | 1920 × 1080 pixels, FHD, 92 PPI |
| Active area | 527.04 × 296.46 mm |
| Viewing area | 530.2 × 299.6 mm |
| Panel structure | a-Si TFT-LCD module |
| Display mode | IPS, normally black, transmissive |
| Selected luminance | 1000 cd/m² |
| Contrast ratio | 1000:1 typical |
| Viewing angle | 89°/89°/89°/89° L/R/U/D |
| Color support | 16.7M colors, 72% NTSC |
| Surface treatment | Anti-glare, 3H hard coating |
| Response time | 14 ms typical, G-to-G |
| Standard refresh rate | 75 Hz |
| Signal interface | 30-pin, two-channel 8-bit LVDS |
| Panel supply | 5.0 V typical |
| Backlight | 18S2P WLED, driver not included |
| Listed backlight life | 30,000 hours |
| Module weight | 2.00 kg typical / 2.10 kg maximum |
The selected technical values are defined at module level and require matching controller, backlight-power and mechanical documentation.
Selected 1000 cd/m² Optical Grade
Lock the Ordered Brightness Version
The 23.8-inch platform includes several luminance grades, but the selected configuration is the 1000 cd/m² version. Procurement should confirm the permitted tolerance, measurement location, warm-up condition and dimming requirement so the sample and production units are assessed against the same optical target.
Validate the Complete Front Window
Finished readability depends on more than panel luminance. Cover-glass transmission, external reflection, printed borders, haze, anti-reflective treatment, air gaps, bonding and installation angle all influence effective contrast.
Test the complete assembly under representative site lighting. A kiosk installed under a canopy, near a window or in direct sun may require different optical and thermal decisions even when the same panel size and resolution are used.
Use IPS Viewing Performance Correctly
The listed viewing-angle order is left, right, up and down. Qualification should include off-axis text, icons, dark-background graphics and video through the intended protective window rather than evaluating only a bare panel positioned directly in front of the observer.
Integrating the Outdoor High Nits Kiosk LCD Module
Qualify the 30-Pin LVDS Connection
Request the complete pin assignment, dual-channel mapping, 8-bit signaling definition, pixel clock, timing, voltage rails, grounds, connector orientation and cable drawing. Matching resolution and connector count are insufficient for controller reuse.
The controller should be validated with the ordered production panel and cable before PCB, harness or firmware release.
Separate Panel and Backlight Power
The listed 5.0 V value applies to the panel supply. It does not define the 18S2P WLED voltage, current, enable logic or dimming method.
The WLED driver is not included, so the system design must provide a compatible backlight driver and confirm startup, shutdown, brightness control and fault behavior.
Treat 75 Hz as the Standard Rate
Use 75 Hz as the baseline panel rate. The additional 120 Hz and 240 Hz descriptions include MEMC or combined panel/backlight wording and should not be interpreted as standard native operation for every ordered configuration.
A higher-motion route requires an approved panel revision, controller architecture and acceptance test.
Mechanical and Environmental Qualification
Distinguish Active Area from Viewing Area
The 527.04 × 296.46 mm active area defines the illuminated image. The 530.2 × 299.6 mm viewing area is a separate front-window reference.
Neither value replaces a complete outline drawing. Obtain the full module width, height, thickness, mounting points, connector location, keep-out zones and tolerances before releasing the enclosure.
Plan for the Module Load
The listed weight is 2.00 kg typical and 2.10 kg maximum. The enclosure should support the panel without twisting the frame or applying concentrated loads to the glass.
The design should also provide service access for the LVDS cable, external WLED driver, controller and thermal components.
Approve the Temperature Revision
Do not release the environmental specification until the approved production datasheet fixes the operating and storage limits.
Temperature capability at panel level also does not establish the protection grade, solar-load tolerance or thermal performance of the finished kiosk. The complete cabinet, front window, backlight, controller and ventilation strategy must be tested together.
Application Fit
The Outdoor High Nits Kiosk LCD Module fits applications that need a conventional widescreen layout with additional luminance and wide-angle viewing.
Outdoor-Facing Kiosks
Information kiosks, wayfinding terminals and self-service equipment can use the FHD image area for menus, instructions, maps and service messages. The final system must define front-glass optics, sealing, cooling and the user-interaction method.
Commercial and Industrial Terminals
The 23.8-inch format supports industrial dashboards, monitoring interfaces, commercial terminals and operator information panels. The 30-pin LVDS connection and 5.0 V panel supply require controller-level verification before production.
Medical-Equipment Interfaces
The panel may be evaluated as an interface component for medical or healthcare equipment, but no medical certification is implied. Regulatory compliance, image-performance requirements, cleaning materials and system safety remain responsibilities of the finished equipment program.
Configuration Options
Project review may cover:
- Brightness-grade selection
- LVDS controller and cable matching
- Cover glass
- AR, AG or AF treatment
- Optical bonding
- Touch integration
- Enclosure adaptation
- Mounting support
- Brightness control
- Higher-frame configurations
- Thermal design
- Branding and packaging
Custom configurations are generally reviewed from 500 pieces, subject to tooling requirements, material availability and the requested specification. Sample and standard-module quantities are confirmed separately.
Procurement Checklist
- Confirm the assigned and supplier model revisions.
- Lock the selected 1000 cd/m² output and tolerance.
- Confirm native 1920 × 1080 timing and 75 Hz operation.
- Obtain the complete 30-pin dual-channel LVDS definition.
- Confirm connector pitch, contact side and orientation.
- Confirm the 5.0 V panel rail and current.
- Obtain WLED voltage, current, enable and dimming data.
- Confirm the external backlight-driver architecture.
- Obtain the complete outline and mounting drawing.
- Confirm the 2.00/2.10 kg structural load.
- Define front glass, coatings, air gap or bonding.
- State the required touch configuration.
- Resolve operating and storage temperature limits.
- Define the required enclosure-protection target.
- Confirm sample criteria, quantity and annual demand.
FAQ
About 23.8 Inch Outdoor High Nits Kiosk LCD Module
What must be checked before connecting a 30-pin LVDS controller?
How does the selected brightness version differ from the wider product family?
Does 1000 cd/m² guarantee readability in direct sunlight?
How should the 75 Hz, 120 Hz and 240 Hz descriptions be interpreted?
Which temperature limits should be approved before production?
