27 Inch Industrial Monitor Display Panel with LVDS
Model P/N
Size
Resolution
Brightness
Viewing Angle
Connector Type
Operating Temp
Overall(mm)
huisoar
HS270ENT-NE10
Brand
Panel Size (inch)
Model P/N
Resolution
Brightness (nits)
Viewing Angle
Contrast Ratio
Response Time
Overall (mm)
Active Area (mm)
Refresh Rate
Bezel Opening
Display Colors
Panel Type
Connector Type
Surface Treatment
Operating Temp
Touchscreen Type
Storage Temp
Work Mode
Pixel Format
Input Voltage (V)
Weight (g)
Operating Environment
Designed For
27 Inch Industrial Monitor Display Panel with LVDS
This 27-inch AMVA Full HD panel delivers 1000 cd/m² typical luminance and two-channel LVDS for bright industrial monitor and workstation builds.
Product Summary
The Industrial Monitor Display Panel provides a 27-inch Full HD image platform for workstation displays, industrial monitors and control-terminal assemblies. Its exact configuration combines 1920 × 1080 resolution, 1000 cd/m² typical luminance, AMVA normally-black operation, 3000:1 typical contrast and a 30-pin two-channel LVDS interface.
The panel is a component rather than a finished monitor. The controller, LVDS cable, WLED driver, enclosure, front window and mounting system must be selected around the final equipment requirements.
A 30-pin LVDS connector does not guarantee timing, voltage, two-channel mapping, bit depth or pin compatibility with another controller.
Key Specifications at a Glance
| Parameter | Confirmed value |
|---|---|
| Display size | 27 inches |
| Resolution | 1920 × 1080 pixels |
| Pixel density | 81 PPI |
| Panel mode | AMVA, normally black, transmissive |
| Active area | 597.6 × 336.15 mm |
| Viewing-area reference | 601.6 × 340.15 mm |
| Luminance | 1000 cd/m² typical |
| Contrast ratio | 3000:1 typical |
| Viewing angle | 89/89/89/89° typical, L/R/U/D |
| Display colors | 16.7M colors, 72% NTSC |
| Interface | 30-pin LVDS, two-channel, 8-bit |
| Panel input | 5.0 V typical |
| Response time | 7/5 ms typical, Tr/Td |
| Refresh reference | 75 Hz listed |
| Surface | Matte, 3H hard coating |
| Weight | 2.18 kg typical |
| Backlight | 15S4P WLED, driver not included |
| Listed backlight life | 40,000 hours |
Full HD AMVA Image Performance
1000 cd/m² Bright-Ambient Use
The RS270ENT-NE10 configuration uses 1000 cd/m² typical luminance. This is the correct public brightness statement for the selected model; the wider 500–2500 cd/m² range describes other members of the product family.
The higher luminance supports use in bright factory spaces, window-adjacent workstations and commercial interiors where a conventional low-brightness monitor panel may lose clarity. It does not, by itself, establish direct-sun readability.
A 1000 cd/m² panel can improve visibility in bright industrial environments, but finished readability still depends on front-window reflection, optical stack and thermal conditions.
Contrast, Color and Wide Viewing
AMVA normally-black operation provides a 3000:1 typical contrast ratio for dark backgrounds, process graphics, status dashboards and workstation content. The panel supports 16.7 million colors with 72% NTSC coverage.
The confirmed viewing-angle sequence is 89/89/89/89° for left, right, up and down at CR ≥ 10. This supports installations viewed from standing, seated or offset positions.
The matte surface and 3H hard coating help manage glare and handling, although the final front glass can change reflection and contrast.
Integrating the Industrial Monitor Display Panel
30-Pin Two-Channel LVDS Qualification
The signal interface is 30-pin, two-channel, 8-bit LVDS. Controller approval should verify:
- Native 1920 × 1080 timing
- Required refresh rate
- Pixel clock
- Two-channel mapping
- 8-bit color mapping
- VESA or JEIDA data convention
- Complete 30-pin assignment
- Connector pitch and contact side
- Cable orientation and length
- Grounding and shielding
- Panel-enable and control signals
A controller should be matched to the exact panel specification rather than selected only by resolution and pin count.
Panel and WLED Backlight Power
The panel logic input is 5.0 V typical. This value does not define the WLED backlight supply or the complete monitor-system input voltage.
The backlight uses a 15S4P WLED structure and is listed without an included driver. Engineering review must therefore confirm:
- Backlight voltage
- LED current
- Dimming method
- Enable signal
- Driver topology
- Thermal protection
- Maximum power
HDMI, DisplayPort, DVI or USB-C require a suitable controller that converts the external source to the approved LVDS signal.
Mechanical and Front-Window Planning
Active Area and Viewing-Area Reference
The active pixel area measures 597.6 × 336.15 mm. A separate 601.6 × 340.15 mm viewing-area reference is provided for front-opening planning.
The complete outline, thickness, mounting points and connector location are not confirmed in the available specification. Enclosure release should wait for an approved mechanical drawing covering:
- Overall dimensions
- Hole locations
- Rear-component keep-out zones
- Connector position
- Cable-bend clearance
- Tolerances
- Structural support
Active area and viewing area are not substitutes for the complete module outline.
Matte Surface and Reflection Control
The panel has a matte surface with 3H hard coating. A protective industrial window can still introduce reflections, tint losses or internal glare.
Front-stack validation should cover:
- Glass transmission
- Surface reflection
- Air-gap distance
- Installation angle
- Ambient-light direction
- Operator viewing position
- Optional AR or AG treatment
- Optical-bonding feasibility
Evaluate the complete monitor assembly under its brightest expected lighting condition.
Refresh and Environmental Boundaries
Refresh-Configuration Confirmation
The specification lists 75 Hz and also refers to higher 120 Hz or 240 Hz family configurations involving MEMC or combined panel/backlight processing.
Higher listed 120/240 Hz modes require exact controller, panel and MEMC configuration confirmation.
Do not describe the selected model as a 120 Hz or 240 Hz panel until the controller architecture, timing, firmware and exact panel configuration are approved.
Temperature and Backlight-Life Qualification
The supplied technical table states an operating range of −20°C to +70°C and storage from −30°C to +80°C. These ranges should be confirmed against the approved RS270ENT-NE10 datasheet before environmental release.
The WLED backlight is listed at 40,000 hours. That value should be tied to its reference luminance, current, temperature and duty-cycle conditions before it is used in maintenance or warranty calculations.
Recommended OEM Applications
The Industrial Monitor Display Panel is suitable for:
- Industrial monitor assemblies
- Professional workstation displays
- Industrial PCs
- Control terminals
- Process-monitoring interfaces
- Bright commercial workstations
- Business and education display terminals
- Custom desktop-monitor products
Medical-equipment integration requires separate regulatory, optical and system qualification. The panel specification alone does not establish medical-device compliance.
Customization and Project Qualification
Project review may include:
- Brightness-grade selection
- LVDS controller matching
- Custom cable definition
- Refresh-mode confirmation
- WLED driver selection
- Cover-glass engineering
- AR or AG surface treatment
- Optical bonding
- Enclosure adaptation
- Mounting design
- Optional touch-overlay development
- Branding and packaging
Touch is not confirmed as part of the standard panel configuration and must be reviewed separately when required.
Custom configurations are generally reviewed from 500 pieces, subject to tooling requirements, material availability and the requested specification. Sample and standard-panel quantities are confirmed separately.
Procurement Checklist
Confirm these items before sample or production approval:
- Exact RS270ENT-NE10 datasheet
- Native 1920 × 1080 timing
- Required 75 Hz or other refresh configuration
- Two-channel, 8-bit LVDS support
- VESA or JEIDA mapping
- Complete 30-pin assignment
- Connector pitch, contact side and orientation
- 5.0 V panel rail
- WLED voltage, current and dimming
- External backlight-driver requirements
- 597.6 × 336.15 mm active area
- 601.6 × 340.15 mm viewing-area reference
- Complete outline and mounting drawing
- Front-window transmission and reflection
- 1000 cd/m² lighting target
- Temperature-range documentation
- Touch requirement
- Compliance-document requirements
- Sample criteria, quantity and annual demand
FAQ
About 27 Inch Industrial Monitor Display Panel
What must be checked before connecting a 30-pin LVDS controller?
Is 1000 cd/m² sufficient behind industrial protective glass?
Which mechanical data are required before enclosure release?
How should the listed high-refresh configurations be qualified?
What is the minimum order quantity (MOQ) for custom display modules with integrated touch and controller boards?
Please contact our sales team with your specific requirements (touch type, controller board, quantity) to receive a tailored MOQ and lead time.
What is the typical refresh rate and response time of your industrial TFT panels for motion graphics or video playback in HMIs?
The typical refresh rate for this industrial TFT panel is 60Hz. Response time is For motion graphics or video playback in HMIs, a 60Hz refresh rate is generally adequate. If you require faster response times for high-speed content, please request the datasheet or confirm with our engineering team for available options.
What are the packaging options for shipping and handling of fragile LCD panels?
Packaging options for shipping and handling of fragile LCD panels are not detailed on this page. Standard practice includes anti-static bags, foam cushioning, and sturdy cartons. For bulk orders, we can provide custom packaging to ensure safe transit. Please confirm your shipping requirements with our logistics team to arrange appropriate packaging.
What are the operating temperature ranges for your industrial LCD panels, especially for extended outdoor use?
For extended outdoor use, ensure the panel is housed in an enclosure that provides thermal management, as direct sunlight and extreme conditions may affect performance. For environments beyond these limits, please consult our engineering team for potential custom solutions.
What are the operating temperature ranges for your industrial control displays, especially for environments below -20°C or above 70°C?
The operating temperature range for this industrial control display is -20°C to +70°C. For environments below -20°C or above 70°C, this panel may not be suitable without additional thermal management. We recommend evaluating your specific environment and, if needed, requesting a custom solution or a different panel with a wider temperature range. Please contact our engineering team for further guidance.
Do you offer displays with In-Cell touch technology that are suitable for automotive dashboards or industrial HMIs with high reliability?
In-Cell touch technology is not offered on this specific model. This panel is without touch. For automotive dashboards or industrial HMIs requiring high reliability, we can discuss alternative touch solutions such as projected capacitive or resistive touch, which can be integrated with this panel. Please contact our sales team to explore options that meet your reliability and performance needs.
