C2150FHF1MB01 21.5″ Embedded Industrial Display Panel 500nits 97%sRGB TIANMA

The C2150FHF1MB01 21.5" Embedded Industrial Display Panel is a high-stability a-Si display solution developed by TIANMA for embedded automation and industrial control scenarios. Mass-produced since Q4 2024, this FHD display features 500nits high brightness and 97% sRGB color accuracy, with an extended wide-temperature design that supports reliable performance in demanding industrial working environments.

Core Performance & Technical Advantages of C2150FHF1MB01

High Brightness & Professional Color Reproduction

This embedded industrial display panel comes with 1920×1080 FHD resolution and RGB vertical stripe pixel layout, delivering sharp visuals for real-time monitoring and control interfaces. The 500 cd/m² typical brightness significantly improves readability in bright industrial spaces, while 97% sRGB color coverage ensures precise color presentation for professional industrial visualization applications. Paired with a 1500:1 contrast ratio, it delivers clear image layering and enhanced detail recognition.

Wide Temperature Reliability & Long-Life Backlight

Built for continuous embedded operation, the C2150FHF1MB01 supports an operating temperature range of -20~70°C and storage temperature of -30~80°C, maintaining stable performance under extreme temperature fluctuations. It uses a 19S4P WLED backlight with a 50,000-hour service life, reducing maintenance requirements for 24/7 running automation equipment. The haze 25% anti-glare surface minimizes reflection interference for on-site operators.

Detailed Technical Specifications of C2150FHF1MB01

All specifications are verified against TIANMA’s Final Ver2.1 datasheet issued in May 2025. The display uses a 30-pin LVDS (2 ch, 8-bit) terminal interface for stable signal transmission and a 5.0V typical driving voltage, compatible with most industrial control and embedded systems. The 60Hz refresh rate ensures smooth real-time data rendering for factory automation equipment.

With an 89/89/89/89 full viewing angle, the screen remains clearly visible from multiple operating positions, improving operational flexibility. The module weighs 1.68kg with a slim 12.85mm profile, allowing seamless integration into compact embedded equipment enclosures without compromising structural stability.

Why Choose C2150FHF1MB01 for Embedded Projects

As a mass-produced embedded industrial display panel with active market supply, the C2150FHF1MB01 offers consistent quality and a secure supply chain for both prototype development and bulk orders. Its wide-temperature construction distinguishes it from standard industrial displays, making it ideal for equipment deployed in unregulated temperature environments.

The standardized LVDS interface simplifies hardware integration and shortens R&D cycles, lowering overall engineering costs. With multiple authorized suppliers and sufficient inventory, this display provides flexible procurement options for industrial automation manufacturers. For the latest production status and technical support, consulting TIANMA or its official agents is highly recommended.

Typical Applications for C2150FHF1MB01

Embedded Automation Control Systems

The C2150FHF1MB01 is widely applied in embedded industrial PCs, factory automation consoles, and production line monitoring systems, where its high brightness and wide-temperature design ensure stable long-term operation.

Harsh Environment Industrial Equipment

It also serves as a premium display component for testing instruments, industrial machinery, and outdoor-connected control devices, adapting to fluctuating temperatures while maintaining consistent visual output for operators.

The C2150FHF1MB01 21.5" Embedded Industrial Display Panel from TIANMA combines high brightness, wide temperature tolerance, and long service life, making it a robust choice for embedded automation and industrial equipment development. For bulk orders, custom integration solutions, or detailed datasheet requests, please contact our sales and technical team to discuss tailored options for your project requirements. Our engineering team can provide full technical guidance to support smooth integration in your embedded system design.
